CEMENTIOUS MIX COATING - Technical Data Sheet
DIBHALITE-PC is Flexible, solvent free, loaded with extenders, two component Epoxy based system [Resin & Hardener ] basically formulated for the bridging the gaps in cracks, cementing the aluminum section in flameproof fitting and fixtures, potting component to capacitor, cable joint kits, Air Filters & Electronic Industries, etc..
Product Specification
| Ratio | Visual Appearance | Viscosity of mix | Pot-life of mix | Curing Time | VEHICLE TYPE |
|---|---|---|---|---|---|
| Resin part 1.0 pbv 1.0 pbw Hardener part 1.0 pbv 1. pb | On curing white | Pourable at 30`C | 40 - 50 Minutes at 30`C Temp. | 2 - 3 Hours at 30`C. | Filler loaded Based on Epoxy Resin system |
Surface Preparation
For better adhesion, it is essential to clean the surface on which the material is to be consumed. To remove dust, dirt, or loose particles by emery paper, wire brush. To get optimum performance the surface must be dry, free from oil grease. For concrete surface, old concrete surface should be examined for structural soundness. Unsound areas must be repaired.
Precaution
Mix only the required quantity of material, which can be utilized within stipulated pot- life to avoid solidification. Wash all the tools and tackles with industrial solvent immediately after the application is completed.
Self - Life / Storage
| Self-life | Packaging | Storage |
|---|---|---|
| Minimum 3 months, stored at cool and dry placed in sealed containers supplied. | 40 kgs,20 kgs, 10 kgs, 2 kgs. | Material should be stored in an enclosed area and away from direct sunlight and heat. |
DIBHALITE- FXWC is Epoxy based Solvent Free Two Component Systems, especially formulated for best performance of Adhesion to Road Studs both on Bitumen and Concrete Surfaces.
Moreover, it’s designed as resistance to UV rays, Water resistance and being inherent flexible properties also resist Expansion and Contraction due to heavy traffic movements along with weather changes during the year.
Moreover, being loaded with specific fillers can also be consumed for Concrete joints in RCC.
Product Specification
| Ratio | Finish | Viscosity of mix | Coverage of mix | Pot-life of mix | TEXTURE | ODOUR |
|---|---|---|---|---|---|---|
| RESIN PART 100 ppts by wt HARDNER PART 50 ppts by wt FILLER ( grey cement) 200 ppts by wt |
Matt | Brush able | 25 – 30 gms per one piece [ 10 mm x 10 mm ] | 20 - 30 Min at 30'c | Smooth | Odorless [while application] |
Surface Preparation
For better adhesion, it is essential to clean the surface on which the material is to be consumed. To remove dust, dirt or loose particles by emery paper, wire brush or blower. To get optimum performance the surface must be dry, free from oil grease. For concrete surface, old concrete surface should be examined for structural soundness. Unsound areas must be repaired and should be cured for required time.
Precaution
Mix only the required quantity of material, which can be utilized within stipulated pot- life to avoid solidification. Wash all the tools and tackles with industrial solvent immediately after the application is completed.
Self - Life / Storage
| Self-life | Packaging | Storage |
|---|---|---|
| Six months, stored in cool and dry place in Sealed Containers | Resin 1000 gms + Hardner 500 gms | Material should be stored in an enclosed area and away from direct sunlight and heat. |
